U.2 Enterprise NVMe SSD
Specification
| Model No. | PE-25J1 |
|---|---|
| Status | Active |
| Grade | Enterprise |
| Capacity | 1920GB/ 3840GB / 7680GB |
| Interface | PCIe® Gen4x4 |
| Form Factor | U.2 2.5 inch |
| Flash Type | 3D eTLC |
| Max Channel | 8 |
| Extended DRAM | DDR4 |
| MTBF | >3 million hours |
| Power Consumption | 20W typ. |
| DWPD | >1 ( 5 yrs) |
| Sequential Read/Write ( up to ) |
7000/5600 MB/s |
| 4K Random Read/ Write ( Up to ) |
900K /160K IOPS |
| Thermal Sensor | Yes |
| Dimension (LxWxH/mm) |
69.85 x 100.45 x 15.00 |
| Op. Temperature | 0°C ~85°C |
| Features |
|
| Application |
|
